| 名称 model | DTF3030-208-6 | DTF3030-208-10 | DTF4030-170 | DTF4030-208-10 | DTF4040-170 | DTF4040-208-10 |
| 水泵尺寸Inlet/outlet at size [ in ] | 3030-208-6 | 3X3-208-10 | 4X3-170 | 4X3-208-10 | 4X4-170 | 4X4-208-10 |
| 最大流量Displacement Q.max[m³/h] | 45 | 78 | 110 | 93 | 130 | 130 |
| 最大扬程Lift H.max[m(ft)] | 92 | 95 | 60 | 85 | 65 | 85 |
| 最大吸程Suction[m(ft)] | 9 | 9 | 9 | 9 | 9 | 9 |
| 转速Speed[rpm] | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 |
| 柴油机型号Engine model | 2V92F | 2V92F | 2V92F | 2V92F | 2V92F | 2V92F |
| 动力Rated power[KW(Hp)] | 14.5(25) | 14.5(25) | 14.5(25) | 14.5(25) | 14.5(25) | 14.5(25) |
| 排量Displacement[ml] | 997 | 997 | 997 | 997 | 997 | 997 |
| 启动方式Starting system | Electric starter | Electric starter | Electric starter | Electric starter | Electric starter | Electric starter |
| 油箱容积Fuel tank capacity[L(gal.] | 6.5 | 6.5 | 6.5 | 6.5 | 6.5 | 6.5 |
| 持续工作时间Continuous working time[h] | 8 | 8 | 8 | 8 | 8 | 8 |
| 外形尺寸Overall dimension(LxWxH)[mm] | 700X600X800 | 700X600X800 | 700X600X800 | 700X600X800 | 700X600X800 | 700X600X800 |
| 重量Dry weight[kg] | 127 | 128 | 129 | 130 | 131 | 132 |
